NR370i |
||
|
System |
Chipset |
IPQ5322(Quad-core @A53 at 1.5 GHz )+QCA8386+QCN6224(QCN9274 customizable) |
|
RAM |
1GB(512MB to1GB customizable) DDR4 |
|
|
FLASH |
256MB(up to 1GB customizable) SPI NAND, eMMCcompatible 4MB(up to32MB customizable) SPI NOR |
|
|
WiFi |
Standard |
IEEE 802.11a/b/g/n/ac/ax/be |
|
Streams |
MU-MIMO: 2×2+4×4(tri-band2x2+2x2+2x2 customizable) |
|
|
Frequency Bands |
2.4GHz-2.483GHz 5.15-5.25GHz, 5.25GHz-5.35GHz, 5.725GHz-5.850GHz (4.9~7.125GHz customizable) |
|
|
Rate |
2.4GHz:688Mbps,5GHz:5765Mbps |
|
|
Recommended clients |
256(2.4G)+256(5G) |
|
|
Modulation |
802.11b: DSSS：DBPSK(1Mbps),DQPSK(2Mbps),CCK(5.5/11Mbps) 802.11a/g: FDM:BPSK(6/9Mbps), QPSK(12/18Mbps), 16QAM(24/36Mbps), 64QAM(48/54Mbps) 802.11n: MIMO-OFDM:BPSK,QPSK,16QAM,64QAM MCS: MCS0~MCS15 802.11ac: MIMO-OFDM:BPSK,QPSK,16QAM,64QAM,256QAM MCS: MCS0~MCS9 802.11ax: MIMO-OFDM:BPSK,QPSK,16QAM,64QAM,256QAM,1024QAM MCS: MCS0~MCS11 802.11be: MIMO-OFDM:BPSK,QPSK,16QAM,64QAM,256QAM,1024QAM, 4096QAM MCS: MCS0~MCS13 |
|
|
Bandwidth |
320/160/80/40/20 MHz |
|
|
Tx power |
24dBm |
|
|
Antenna |
6×External high gain antennas |
|
|
5G NR |
Frequency Bands |
5G SA: n1/n2/n3/n5/n7/n8/n12/n13/n14/n18/n20/n25/n26/n28/n29/n30/n38/n40/n41/n48/n66/n70/n71/n75/n76/n77/n78/n79 5G NSA: n1/n2/n3/n5/n7/n8/n12/n13/n14/n18/n20/n25/n26/n28/n29/n30/n38/n40/n41/n48/n66/n70/n71/n75/n76/n77/n78/n79 LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B12/B13/B14/B17/B18/B19/B20/B25/B26/B28/B29/B30/B32/B66/B71 LTE-TDD: B34/B38/B39/B40/B41/B42/B43/B48 LAA: B46 WCDMA: BB1/B2/B4/B5/B8/B19 |
|
5G rate |
5G SA:DL 2.4 Gbps; UL 900 Mbps 5G NSA：DL 3.3 Gbps; UL 550 Mbps |
|
|
SIM slot |
2×SIM slot |
|
|
Antenna |
4×External high gain antennas |
|
|
Wired |
Network interface |
1×10GSFPWAN, 4×2.5GbpsLAN(PoEout)； Note：LAN1 supports switching to a WAN port. |
|
PoE |
LANports support802.3af/atPoEout |
|
|
Powering |
Method |
1. 12~54V DC; 2.3 Pin Phoenix connector(5.08mm) Note: To ensure PoE function 48V input must be guaranteed |
|
Power consumption |
24W(not includingPoE output) |
|
|
Physical |
Dimension |
220*131.5*38mm |
|
Weight |
1.3kg |
|
|
Operating Temperature |
-10℃ ~ + 50℃ |
|
|
Storage Temperature |
-40℃～+ 85℃ |
|
|
Operating humidity |
5%~90%(non-condensation) |
|
|
Mounting |
Desktop |
|
|
Other interfaces |
Indicators |
Power,Eth, 5G, WiFi, USB |
|
Button/Jack |
Reset/WPS in one, RJ45 Console, USB2.0 |
|
